In the realm of BitVM-like protocols, where computations and commitments are verified on-chain through hash-based techniques, one-time signatures (OTS) such as Winternitz are frequently used. These schemes offer a simple and script-compatible way to commit to values and prove computations in Taproot-based contracts.

We discovered a vulnerability that can be exploited by a malicious party to steal funds by forcing a timeout, especially in turn-based protocols. The issue arises when the victim is unable to submit their on-chain response due to Bitcoin's transaction size and policy constraints.

🧩 The Vulnerability

In the Taproot script used on these protocols, parties often rely on OP_SHA256 or OP_HASH160 to verify an input value committed earlier. Typically, this value is used in another transaction by the counterparty to prove that it is incorrect—using a script that verifies the input after verifying it with a one-time signature.

These verification scripts are agreed upon during the protocol's setup phase. The public key of the one-time signature is known in advance, but the private key remains secret until a participant decides to reveal it in order to commit a value.

The problem is that these scripts often do not check the size of the preimage. While the hash result has a fixed size (32 or 20 bytes), the preimage used during verification can be anything up to 520 bytes (the stack element limit in Bitcoin Script). This opens the door to an unexpected attack.

🎯 The Exploit

A malicious party (e.g. the prover) can publish a commitment with a large preimage—say 400 or 500 bytes. Since they know their own verification script and can optimize the witness size, they are able to publish a valid transaction that includes the large preimage and the corresponding signature.

The other party (e.g. the verifier), in turn, attempts to respond by posting a transaction containing their version of the verification script and the same preimage. But this time, the increased witness size might exceed transaction limits, especially when combined with their more complex script or other inputs.

As a result, they cannot post their transaction at all—either because it's non-standard, too large for consensus rules, or too expensive to relay.

Since these protocols are often turn-based, the attacker can now wait out the timeout, win the dispute, and steal the funds.

There is another attack vector that can be exploited. If the client application responsible for decoding the transaction witness expects the preimage to be a fixed-size binary string (20 or 32 bytes), it may be unable to parse the witness and extract the value. This could cause the client to halt with an error, raise an exception, or skip transaction processing altogether. In all these cases, the client would fail to perform the challenge, and if the issue is not fixed in time, the attacker would win.

🔐 Mitigation: Enforce Preimage Size

The fix is simple and should be included in all verification scripts:

OP_DUP OP_SIZE <20 or 32> OP_EQUALVERIFY

Depending on whether you're using OP_HASH160 (20 bytes) or OP_SHA256 (32 bytes), this enforces that the preimage is exactly the size of the hash output, preventing the attack.

In some systems, the design may intentionally allow preimages of smaller size—such as 128-bit values—without introducing any security degradation in the specific application. In such cases, instead of OP_EQUALVERIFY, it may be appropriate to use OP_GREATERTHAN followed by OP_VERIFY to sanitize the witness accordingly.

🛠️ Alternative Mitigations

In addition to enforcing the preimage size in Script, here are two alternative mitigation strategies that can be implemented at the protocol design level:

1. Zero-Knowledge Proof (ZKP) During Setup
